    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader

    Ask Lasest Price
    Brand Name : GS
    Model Number : HD-100
    Certification : no
    Supply Ability : 5000 Piece/Pieces per Month
    Price : $90.00/pieces 100-499 pieces
    • Product Details
    • Company Profile

    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader

    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader
    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader
    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader
    1. Support ISO/IEC 7816-1/2/3 contact CPU card, ISO/IEC 14443-A/B/C contactless card, ISO/IEC 7811 magnetic stripe card, ID card
    2. Support 4 PSAM card security modules and support high-speed PSAM card security transaction authentication
    3. Contact card communication rate supports up to 307200bps, non-contact card communication rate up to 424Kbps
    4. Full-speed USB interface, easy to install, no need to install additional drivers, easy to operate
    5. Support online program upgrade, provide application standard DLL dynamic library interface under various platforms such as Windows/Linux/Unix
    Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader
    model
    HD-100
    Main processor
    32-bit processor, frequency 72MHz, industrial grade
    Contact card reader module
    Support standard:ISO/IEC 7816 1/2/3 standard
    Card category: contact CPU card, logic encryption card 4442/4428, Memory card, etc.
    Support rate: 9600 ~ 307200bps
    Protection mechanism: short circuit protection, protection for any contacts and short circuit
    Number of card slots: 2 standard embedded SAM card slots
    Card insertion life: more than 100,000 times
    Contactless card reader module
    Supporting standards: ISO/IEC 14443 A/B/C standard
    Card type: Mifare One, contactless A, B card
    Support rate: 106~424Kbps
    Card reading distance: greater than 5CM
    Magnetic stripe reading module
    Support standard: ISO/IEC 7811
    Support for tracks: 1/2 track or 2/3 track
    Swipe direction: two-way
    USB
    Support HID, CCID, PC/SC protocol, support analog keyboard output protocol communication rate 12Mbps length 1.5 meters, with
    magnetic ring
    Serial port (optional)
    Support standard RS232 interface, 485 interface communication rate support 9600~115200bps
    Power supply
    DC5V±5%, USB power, standby 30mA, working current 250mA
    Short circuit protection
    reverse polarity protection, over current protection, short circuit protection
    Working environment
    temperature -20 ° C ~ 105 ° C humidity 5% ~ 90% without condensation
    Indicator light power
    Highlight red Communication: Highlight green
